Twisted pair cable 4 pairs for installation and use in closed conditions (indoors). Twisted pair is a universal cable with wide application. During network operation, the cable is designed to transmit signals with a frequency range up to 155 MHz. The conductor core is made of pure copper, and externally the cable is covered with a polyvinyl chloride sheath. The cable's cross-section diameter is 0.51 mm, and the type of network cable is UTP. In network operation conditions with constant electric current, the twisted pair can produce resistance up to 9.6 Ohm/100 m. The cable is adapted to work with all the most common working interfaces with data transmission traffic capability of 100/150 Mbps.
The cable is made entirely of high-quality materials, which makes it resistant to the influence of external factors. The twisted pair is designed for long-term operation, and even in the case of multiple or prolonged use, it does not lose its basic technical characteristics. The recommended environmental temperature range is -30 °C / +60 °C.
The set includes 4 pairs of category 5e, with a length of 305 meters. The conductor is quite easy to install and compactly fits in a storage box. The twisted pair is manufactured in accordance with international quality control - ISO/ANSI, and also meets the national quality standard - GOST and DSTU.
Construction:
1. Conductive core: soft copper wire
- Diameter: 0.51 mm (24 AWG
2. Insulation: polyethylene
- Conductor diameter: 0.96 mm
- Pair: 2 twisted together conductors
- Color identification of cores:
- pair 1: white-blue / blue
- pair 2: white-orange / orange
- pair 3: white-green / green
- pair 4: white-brown / brown
- Core: 4 pairs twisted together
3. Outer sheath: polyvinyl chloride plastic (PVC) or LS0H compound
- Maximum cable diameter: 5.9 mm
Compliance with requirements:
- ISO/IEC 11801:2002
- EN 50173-1:2002
- ANSI/TIA/EIA-568-B.2-2001
- IEC 61156-5:2002
- TU U 31.3-05758730-020-2002
